Features :

1.

Oval dome : with the design for the minimum wind resistance. Black painting of top dome stops sunlight from passing through. It will clearly show the light effects of the light bars in the daytime.

2.

To assemble each two of halogen rotators per side in the light bar. The rotators match with reflexible mirrors as a result of emitting the more powerful lights.

3.

As per customer's option, available for one alley light per end side in light bar.

4.

Low power micro motor fits with worm gear for driving durably and quietly. The axle of the rotator contains oil impregnated metal, no need of lubricating oil.

5.

The raw materials for speaker housing, all screws / nuts & mounting bracket are stainless steel.

6.

Each set of light bar includes Bulb Burn-out Indicator one pce. It can control light bar & detect the burned-out bulb if any. It may also consolidate with Electronic Siren by request.

Colors availableRed, Yellow and Blue color are standard, transparent color is optional

Specifications :

Model

Voltage

Current

Flashing rate

Bulb

Rotating
Light

Reflector

Alley
Ligth

Number
of speaker

Weight

HTM-12

DC 12V

27.5A

100∮10 FPM

12V 55W x 4
12V 55W x 2

4 Set

8 Pcs

2 Set

1 Set

12.5 kg

HTM-24

DC 24V

17.5A

100∮10 FPM

24V 70W x 4
24V 70W x 2

4 Set

8 Pcs

2 Set

1 Set

12.5 kg

/ ...Halogen Bulb

Remark :  The weight of all above models is not including that of mounting bracket and speakers.
